Havit LED Driver w/Flex & Plug Weatherproof 150W 240V Aluminium IP66 Silver F/All Low Voltage Light Fittings & LED Strip

Description

LED Driver Weatherproof, 240 Volt AC Input Voltage, 24 Volt DC Output Voltage, 150 Watt, 6.25 Amp, 47/63 Hz, Non-Dimmable, For Use With All Low Voltage Light Fittings and LED Strip, 120 Watt Max. Load, IP66, >=0.9 Power Factor, Aluminium, Silver, 25 to 50 deg C, 247 mm Length, 68 mm Width, 46 mm Height

Key Specifications

SKU	HAVHV9658-24V150W
Brand	Havit
Product Type	Drivers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	High power factor Constant voltage design High input voltage Small dimension, high efficiency, high reliability, long lifetime IP66 design for outdoor installation Protections: overload, over voltage, short-circuit, etc Typically efficiency: 90.5% CE/IP66 certified, RoHS Complaint 100% full load burn-in test
Standard Pack Size	1
UNSPSC Class	39101900
UOM	EA
Vendor Product	HV9658-24V150W
Colour	Silver
Current	6.25 Amp
Dimmable	Non-Dimmable
For Use With	All Low Voltage Light Fittings and LED Strip
Frequency	47/63 Hz
Height	46 mm
Input Voltage	240 Volt AC
IP Rating	IP66
Material	Aluminium
Max. Load	120 Watt
Output Voltage	24 Volt DC
Power Factor	>=0.9
Wattage	150 Watt
Temperature	25 to 50 deg C
Width	68 mm
