Tele Fonika Flexible Wire Single Insulated 1 Core 4mm 0.6/1kV Tinned Copper X-HF-110 PVC Green/Yellow
Description
Flexible Cable, 4 mm, Class 5 Tinned Copper, 0.6-1 kV, 57 Amp, 1 Core, 0.31 mm Strands, 3.9 mm Overall Diameter, 15.6 mm Bend Radius, 0.7 mm Insulation Thickness, 4.95 Ohm/km Conductor Resistance, X-HF-110 PVC Insulation, Green/Yellow Insulation, Unsheathed Sheath, Flexible -40 to 110 deg C
Key Specifications
| Barcode (EAN-13) |
4044774292519
|
|---|---|
| SKU |
DKSHF1X4GN/YW
|
| Brand |
Lapp Kabel
|
| Product Type |
Flexible Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 100 |
| UNSPSC Class | 26121500 |
| UOM | MTR |
| Vendor Product | HF1X4GN/YW |
| Bend Radius | 15.6 mm |
| Conductor Resistance | 4.95 Ohm/km |
| Conductor Size | 4 mm |
| Conductor Type | Class 5 Tinned Copper |
| Current | 57 Amp |
| Insulation Colour | Green/Yellow |
| Insulation Material | X-HF-110 PVC |
| Insulation Thickness | 0.7 mm |
| Overall Diameter | 3.9 mm |
| Number of Cores | 1 Core |
| Sheath Material | Unsheathed |
| Stranding | 0.31 mm |
| Temperature | Flexible -40 to 110 deg C |
| Voltage | 0.6-1 kV |
