Elcon 1.5mm Blue Flexible Wire Heavy Duty V90HT PVC

Description

Flexible Wire, Heavy Duty, 1.5 mm, Class 5 Tinned Annealed Copper, 0.6-1 kV, 21 Amp, 1 Core, 30/0.25 mm Strands, 3.15 mm Overall Diameter, 0.8 mm Insulation Thickness, DC: 13.7 MOhm/m Insulation Resistance, V-90HT PVC Insulation, Blue Insulation, Unsheathed, 90 deg C, AS/NZS 1125 AS/NZS 3808:2000 AS/NZS 3191

Key Specifications

SKU	ELNCF-FHDT130025L100
Brand	Elcon Cables

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	RoHS Compliant Excellent flexibility UV resistant 99.9% OFHC (Oxygen Free High Conductivity) Copper which does not show any brittleness
Standard Pack Size	100
UNSPSC Class	26121500
UOM	MTR
Vendor Product	CF-FHDT130025L100
Conductor Size	1.5 mm
Conductor Type	Class 5 Tinned Annealed Copper
Current	21 Amp
Insulation Colour	Blue
Insulation Material	V-90HT PVC
Insulation Resistance	DC: 13.7 MOhm/m
Insulation Thickness	0.8 mm
Overall Diameter	3.15 mm
Number of Cores	1 Core
Sheath Material	Unsheathed
Standards	AS/NZS 1125 AS/NZS 3808:2000 AS/NZS 3191
Stranding	30/0.25 mm
Temperature	90 deg C
Voltage	0.6-1 kV
