Treotham 1.5mm 6 Core + Earth Black Flexible Cable Heavy Duty EPR/CPE
Description
Flexible Cable, Heavy Duty, 1.5 mm, Class 5 Copper, 0.6-1 kV, 6 Core + Earth, 15 mm Overall Diameter, 75 mm Bend Radius, >=1 MOhm/km Insulation Resistance, Green/Yellow/Black Numerals Core, EPR Insulation, CPE Sheath, Black Sheath, -25 to 90 deg C, IEC 60332-1
Key Specifications
| SKU |
TRETA35.0015.07
|
|---|---|
| Brand |
Treotham
|
| Range Name |
H07 RN-F
|
| Product Type |
Flexible Cable Heavy Duty
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | TA35.0015.07 |
| Bend Radius | 75 mm |
| Conductor Size | 1.5 mm |
| Conductor Type | Class 5 Copper |
| Core Colours | Green/Yellow/Black Numerals |
| Insulation Material | EPR |
| Insulation Resistance | >=1 Mohm/km |
| Number of Cores | 6 Core + Earth |
| Overall Diameter | 15 mm |
| Sheath Colour | Black |
| Sheath Material | CPE |
| Standards | IEC 60332-1 |
| Temperature | -25 to 90 deg C |
| Voltage | 0.6-1 kV |
