ABB Electric Motor Squirrel Cage Induction 4P 2.2kW 3Ph 400Y/230D/380Y/220D/440Y/460YV 100LB Frame Flange Mount
Description
Electric Motor Squirrel Cage Induction, 400 Y/230 D/380 Y/220 D/440 Y/460 Volt, 4.38 Y/7.67 D/4.53 Y/7.83 D/4.02 Y/3.90 Amp, 2.2 kW, 50/60 Hz, 3 Phase, 1437 Y/1436 D/1428 Y/1429 D/1739 Y/1745 rpm, 4 Pole, IP55, Frame: 100LB, Shaft Size: 28 mm, Both (CW and CCW) Rotation, Duty Cycle: S1, Ball Bearing, Torque: 14.62 Y/14.62 D/14.7 Y/14.7 D/12.08 Y/12.04 Y N/m, Flange Mount, Insulation Class: ICLF, 40 deg C, Cast Iron, Munsell Blue, 376 mm Length x 240 mm Height, Please Note: Large Flange
Key Specifications
| SKU |
ABB3GBA102520-BSD
|
|---|---|
| Brand |
ABB
|
| Range Name |
M2BAX
|
| Product Type |
Motors SCIM
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26101100 |
| UOM | EA |
| Vendor Product | 3GBA102520-BSD |
| Colour | Munsell Blue |
| Current | 4.38 Y/7.67 D/4.53 Y/7.83 D/4.02 Y/3.90 Y A |
| Bearing Type | Ball |
| Frame | Size 100LB |
| Height | 240 mm |
| Frequency | 50/60 Hz |
| Insulation Class | ICLF |
| IP Rating | IP55 |
| Horsepower | 2.2 kW |
| Mounting Method | Flange |
| Material | Cast Iron |
| Number Of Poles | 4 Pole |
| Please Note | Large Flange |
| Phase | 3 Phase |
| Rotation | Both (CW and CCW) |
| Shaft Size | 28 mm |
| Speed | 1437 Y/1436 D/1428 Y/1429 D/1739 Y/1745 Y rpm |
| Temperature | 40 deg C |
| Voltage | 400Y-230D-380Y-220D-440Y-460Y Volt |
| Torque Rating | 14.62 Y/14.62 D/14.7 Y/14.7 D/12.08 Y/12.04 Y N/m |
