Connectwell Rail Terminal Block Screwed Grey Polyamide 66

$Connectwell\Connectwell_CF4U.jpg$

Description

These terminal blocks are used in electrical and control systems which require fuse protection. The CF series accepts industry standard 5 x 20 mm and 5 x 25 mm glass cartridge fuses. These blocks are completely closed and do not need a separate end plate.

Key Specifications

SKU	ALSCF4U
Brand	Connectwell
Product Type	Rail Terminal Blocks

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	39121400
UOM	EA
Vendor Product	CF4U
Colour	Grey
Conductor Size	0.2-4mm
Current Rating	6.3 Amp
Depth	8 mm
Height	50.3 mm/57.6 mm/56.5 mm
Insulation Material	Polyamide 66
Mounting Method	DIN 32/35/35-15
Number of Conductors	2
Number of Connection Points	2
Number of Levels	1
Rated Surge Voltage	8 kV
Voltage Rating	1000 Volt
Terminal Type	Screw Clamp
Tightening Torque	0.5 Nm
Width	57 mm
Wire Entry Orientation	Side
Wire Strip Length	9.5 mm
