Belden DataConnect Patch Cord CAT6 UTP RJ45 4 Pair 26 AWG Blue 1.0 mtr

$Belden\Belden_RA6PC1M-BU.jpg$

Description

Data Connect Cat 6 UTP Patch Cord, 26 AWG, RJ45 Connector A, 1 mtr Cord Length, 20 MOhm Contact Resistance, 500 MOhm/min Insulation Resistance, 1000 Volt AC RMS Dielectric Strength, 4 Pair, Brass plated with 50 micron Gold Over 100 micron Nickel Undercoat Contact, Polycarbonate Insulation, Blue Sheath, 10 to 60 deg C

Key Specifications

SKU	BELRA6PC1M-BU
Brand	Belden

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	43223300
UOM	EA
Vendor Product	RA6PC1M-BU
Conductor Size	26 AWG
Connector A	RJ45
Contact Material	Brass plated with 50 micron Gold Over 100 micron Nickel Undercoat
Contact Resistance	20 MOhm
Cord Length	1 mtr
Dielectric Strength	1000 Volt AC RMS
Insulation Material	Polycarbonate
Insulation Resistance	500 MOhm/min
Pair Count	4 Pair
Sheath Colour	Blue
Temperature	10 to 60 deg C
