CMP Products Flame Proof Cable Gland Armoured 6.1-13.1mm M20 IP68

chevron-left

Description

chevron-down
Grooved Cone (X) is predominantly used for Wire Braid (e.g. GSWB, TCWB), Steel Tape Armour (STA, DSTA) and Aluminium Strip Armour (ASA) but is also suitable for Single Wire Armour (SWA), Aluminium Wire Armour (AWA) and Pliable Wire Armour (PWA) if the range is outside that of the Stepped Cone (W).

Key Specifications

chevron-down
SKU
CMP20S16T3CDS1RA5
Brand
CMP Products
Range Name
Triton CDS T3CDS
Product Type
Cable Glands Hazardous Area

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Fully sequential, three step installation procedure
  • Reduces installation times, cost and risk
  • Direct and remote installation
  • Unique compensating displacement seal system - metal-to-metal installation every time regardless of cable diameter
  • Designed to prevent cold flow
  • Integral protected deluge seal
  • Controlled outer *load retention* seal
  • Unique OSTG prevents overtightening
  • EMC tested
Standard Pack Size 1
UNSPSC Class 39121400
UOM EA
Vendor Product 20S16T3CDS1RA5
Body Material Brass
Finish Nickel Plated
Hazardous Area Rating Exd IIC Gb, Exe IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Exd I Mb, Exe I Mb
IP Rating IP68
Max. Armour Wire 1.2 mm
Max. Bedding OD 8.7 mm
Max. Sheath OD 13.1 mm
Min. Armour Wire 0.8 mm
Min. Sheath OD 6.1 mm
Protrusion Length 78.7 mm
Seal Material Thermoset Elastomer
Temperature -60 to 30 deg C
Thread Length 15 mm
Thread Size M16
Width Across Corners 26.4 mm
Width Across Flats 24 mm
