CMP Products Breather/Drain Plug Explosive Atmosphere M20 Brass Exd IIC Gb/Ex ta IIIC D
Description
Breather/Drain Plug, Explosive Atmosphere, Gland Size M20, 15 mm Thread Length, 1.5 mm Pitch, Exd IIC Gb/Ex ta IIIC D, 30 mm Width Across Flats, 33 mm Width Across Corners, 7 N/m, IP66, Brass Body, -60 to 130 deg C, 12.7 mm Protrusion Length
Key Specifications
| Barcode (EAN-13) |
5052625133057
|
|---|---|
| SKU |
CMP781DM25
|
| Brand |
CMP Products
|
| Product Type |
Hazardous Area Accessories
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | 781DM25 |
| IP Rating | IP66 |
| Hazardous Area Rating | Exd IIC Gb/Ex ta IIIC D |
| Cable Gland Size | M20 |
| Protrusion Length | 12.7 mm |
| Temperature | -60 to 130 deg C |
| Torque Rating | 7 Nm |
| Thread Length | 15 mm |
| Width Across Corners | 33 mm |
| Width Across Flats | 30 mm |
| Thread Pitch | 1.5 mm |
