Flexible Cable 1 Core 25mm 0.6/1KV Copper XLPE Orange
Description
Flexible Cable, 25 mm, Annealed Copper, 0.6-1 kV, 1 Core, 193/0.39 mm Strands, 11.4 mm +/-10% Overall Diameter, 175 mm Bend Radius, 0.9 mm Insulation Thickness, 1.4 mm Sheath Thickness, X-90 XLPE Insulation, TP-90 XLPE Sheath, Orange Sheath, 90 deg C, AS/NZS 5000.1 AS/NZS 1125 IEC 60228 AS/NZS 3808
Key Specifications
| SKU |
ELCFXLPE1250
|
|---|---|
| Brand |
Electra
|
| Product Type |
Flexible Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121500 |
| UOM | MTR |
| Vendor Product | FXLPE1250 |
| Bend Radius | 175 mm |
| Conductor Size | 25 mm |
| Conductor Type | Annealed Copper |
| Insulation Material | X-90 XLPE |
| Insulation Thickness | 0.9 mm |
| Overall Diameter | 11.4 mm +/-10% |
| Number of Cores | 1 Core |
| Sheath Colour | Orange |
| Sheath Material | TP-90 XLPE |
| Sheath Thickness | 1.4 mm |
| Standards | AS/NZS 5000.1 AS/NZS 1125 IEC 60228 AS/NZS 3808 |
| Stranding | 193/0.39 mm |
| Temperature | 90 deg C |
| Voltage | 0.6-1 kV |
