IME Mining Earth Leakage Relay 240VAC 0.03mA-5A 2CO Panel Mount 72x72x75mm

chevron-left
loader
Loading...

Description

chevron-down
Earth Leakage Relay Mining, 240 Volt AC, 5 Amp, 3.5 Watt, 2CO Configuration, 0.5 sec Operating Time, Fast-On Crimp Terminal, IP20/IP40, Panel Mounting, Polycarbonate Body,-5 to 60 deg C, 72mm Height, 72mm Width, 75mm Depth

Key Specifications

chevron-down
SKU
IMEDSRM72C240
Brand
IME
Product Type
Relays

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • 1 x Trip change-over contact
  • Second change over latching contact selectable trip or power fail
  • LED indication 20%, 30, 40% and 50%
  • Field selectable positive or negative security
  • 30 mA to 5 Amp sensitivity and up to 0.5 sec time delay
  • Harmonic filter
Standard Pack Size 1
UNSPSC Class 39122300
UOM EA
Vendor Product DSRM72C240
Depth 75mm
Mounting Method Panel
Contact Configuration 2 Changeover
IP Rating IP20/40
Height 72mm
Power Rating 3.5 Watt
Temperature -5 to 60 deg C
Terminal Type Fast-On Crimp
Voltage 240 Volt AC
Width 72mm
