IME AC Ammeter Analogue Moving Iron Direct Connection 0-10A x 5 90Deg 48mm W Panel Mount

chevron-left

Description

chevron-down
AC Ammeter Analogue Moving Iron, 0 to 10 Amp With x 5 Over-Scale, 600 Volt AC, 0-10/50 Amp, 50/45-65 Hz, Direct Connection, 90 deg Deflection Accuracy Class 1.5, -25 to 50 deg C, Analogue Display, 48 mm Height x 48 mm Width, Panel Mount, Polycarbonate, 45 mm Height x 45 mm Width x 69 mm Depth

Key Specifications

chevron-down
Barcode (EAN-13)
9321807023711
SKU
IMERQ48EAAC10A
Brand
IME
Range Name
RQ48
Product Type
Ammeters

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Accuracy class 1.5
  • IP52 rated front frame
Standard Pack Size 1
UNSPSC Class 41113600
UOM EA
Vendor Product RQ48EAAC10A
Current 0-10/50 Amp
Depth 69 mm
Display Analogue
Frame Size 48mm x 48mm
Frequency 50/45-65 Hz
Height 45 mm
Mounting Method Panel
Operation Form Direct Connection
Readout Form 90 deg Deflection Accuracy Class 1.5
Scale 0 to 10 Amp with x5 Over-Scale
Voltage 600 Volt
Temperature -25 to 50 deg C
Width 45 mm
