IME DC Ammeters Analogue Moving Iron 0-10A 90Deg 72mm W Panel Mount

chevron-left

Description

chevron-down
DC Ammeters Analogue Moving Iron, 0 to 10 Amp, 10 Amp, 90 deg Deflection Accuracy Class 1.5, -25 to 50 deg C, Analogue Display, 72 mm Height x 72 mm Width, Panel Mount, Polycarbonate, 68 mm Height x 68 mm Width x 69 mm Depth

Key Specifications

chevron-down
Barcode (EAN-13)
9321807024633
SKU
IMERQ72MADC10A
Brand
IME
Range Name
RQ72
Product Type
Ammeters

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Accuracy class 1.5
  • IP52 rated front frame
Standard Pack Size 1
UNSPSC Class 41113600
UOM EA
Vendor Product RQ72MADC10A
Current 10 Amp
Depth 69 mm
Display Analogue
Frame Size 72mm x 72mm
Height 68 mm
Mounting Method Panel
Readout Form 90 deg Deflection Accuracy Class 1.5
Scale 0 to 10 Amp
Temperature -25 to 50 deg C
Width 68 mm
