NHP DIN-SAFE RCBO 3 Pole+N 10kA 63A C Curve 30mA Type A RCD 54mm

Description

Residual Current Device, 400-415 Volt, 63 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 30 mA Trip Sensitivity, C Curve, 3 + N Pole, 54 Module, Fork/Pin Connection, IP20/40, DIN Rail Mounting, 5 to 40 deg C, 117.5 mm Height, 53.4 mm Width, 71.6 mm Depth

Key Specifications

SKU	NHPDSRCBT6330A
Brand	NHP
Range Name	Din-Safe

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	DSRCBT DIN-T RCBOs feature 10 kA short circuit rating C-Curve for general light, power and motor starting applications Type A RCD 30 mA sensitivity for general personnel protection applications Compact 3P (54 mm) width space saving Neutral pigtail (900 mm) saving cable and installation time Padlockable and sealable toggle restricts unauthorised action Free tripping mechanism even if toggle is locked or sealed ON or OFF Fast connection pin/fork busbar comb or NC or GB busbar chassis Suits metal loadcentres and the Concept range of panelboards
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCBT6330A-NLA
Current	63 Amp
Connection Type	Fork/Pin
Height	117.5 mm
Depth	71.6 mm
Modules	54 Module
Frequency	50/60 Hz
Interrupt Capacity	10 kA
Mounting Method	DIN Rail
IP Rating	IP20/40
Number Of Poles	3 Pole
Temperature	5 to 40 deg C
Trip Characteristic	C Curve
Trip Sensitivity	30 mA
Voltage	400-415 Volt
Width	53.4 mm
