NHP MOD6 RCBO 1P+N 6kA 16A C Curve 30mA Type A No Pigtail

chevron-left

Description

chevron-down
Residual Current Device, 230-240 Volt, 16 Amp, 50/60 Hz, 6 kA Interrupt Capacity, 30 mA Trip Sensitivity, C Curve, 1 + N Pole, Fork/Pin Connection, IP20/40, DIN Rail Mounting, 5 to 55 deg C, 86 mm Height, 36 mm Width, 76 mm Depth

Key Specifications

chevron-down
SKU
NHPMOD6RCBO21630A
Brand
NHP
Range Name
MOD6

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • MOD6 RCBOs feature 6 kA short circuit rating
  • Type AC or Type A RCD with switched neutral
  • 30 mA sensitivity for general personnel protection applications
  • 10 mA sensitivity option for higher risk applications
  • C trip curve for general light and power applications
  • Fast connection pin/fork bus bar comb
  • Suits pole covers and loadcentres
  • Approval No NSW17482 or RCM
  • Energy Safe Victoria (ESV) compliant for residential applications
  • 10mA units compliant with Type 1 requirements
Standard Pack Size 1
UNSPSC Class 39121600
UOM EA
Vendor Product MOD6RCBO21630A
Current 16 Amp
Connection Type Fork/Pin
Height 86 mm
Depth 76 mm
Frequency 50/60 Hz
Interrupt Capacity 6 kA
Mounting Method DIN Rail
IP Rating IP20/40
Number Of Poles 1 Pole
Temperature 5 to 55 deg C
Trip Characteristic C Curve
Trip Sensitivity 30 mA
Voltage 230-240 Volt
Width 36 mm
