Panduit Ring Terminal Insulated Single Grip 0.5-1mm M4 Stud Red 23.1mm OAL

Description

Ring Terminal, Insulated, Single Grip, Conductor Size: 0.5-1 mm, Stud Size: M4, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Funnel, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Red Insulation, Tin Plated Finish, 221 deg F, 23.1mm Overall Length, 11.6mm Lug Length, 7.9mm Lug Width, 0.8mm Lug Thickness, 4.3mm Lug Inside Diameter, Barrel Length: 9.9mm, Max. Insulation Diameter: 3.8mm, 25 Pack

Key Specifications

SKU	PANEV18-8RB-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV18-8RB-Q
Barrel Length	9.9 mm
Barrel Type	Funnel
Conductive Material	Copper
Body Material	Copper
Conductor Size	0.5-1mm
Insulation Colour	Red
Finish	Tin Plated
Lug Inside Diameter	4.3 mm
Insulation Material	Vinyl
Insulation Diameter	3.8 mm
Lug Length	11.6 mm
Lug Thickness	0.8 mm
Lug Width	7.9 mm
Mounting Method	Free Hanging
Pack Size	25 Pack
Overall Length	23.1 mm
Stud Size	M4 Stud
Seam Type	Butted
Temperature	221 deg F
Terminal Type	Circular
Voltage Rating	600 Volt
Wire Strip Length	7.9 mm
