Ralos H07RN-F Power & Control Cable 2 Core + Earth 4mm 600/1000V Tinned Copper Rubber/Rubber Black
Description
Flexible Control Cable, 4 mm, Class 5 Tinned Annealed Copper, 0.6-1 kV, 2 Core + Earth, 13.5 mm Overall Diameter, Static 40.5 mm Flexible 54 mm Mech Load 81 mm Bend Radius, 1 mm Insulation Thickness, 1.9 mm Sheath Thickness, 5.09 Ohm/km Conductor Resistance, Blue/Brown/Green/Yellow Core, EPR Insulation, EM2 CPE Sheath, Black Sheath, Static -40 to 90 deg C Flexible -25 to 90 deg C, BS EN 50525-2-21 IEC 60092-353 AS/NZS 5000.1 IEC 60331-2
Key Specifications
| SKU |
RALRB3G4
|
|---|---|
| Brand |
Ralos
|
| Range Name |
H07RN-F
|
| Product Type |
Flexible Control Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | RB3G4 |
| Bend Radius | Static 40.5 mm - Flexible 54 mm - Mech Load 81 mm |
| Conductor Resistance | 5.09 Ohm/km |
| Core Colours | Brown/Blue/Green/Yellow |
| Conductor Size | 4 mm |
| Conductor Type | Class 5 Tinned Annealed Copper |
| Insulation Material | EPR |
| Insulation Thickness | 1 mm |
| Number of Cores | 2 Core + Earth |
| Overall Diameter | 13.5 mm |
| Sheath Colour | Black |
| Sheath Material | EM2 CPE |
| Sheath Thickness | 1.9 mm |
| Standards | BS EN 50525-2-21 IEC 60092-353 AS/NZS 5000.1 IEC 60331-2 |
| Temperature | Static -40 to 90 deg C Flexible -25 to 90 deg C |
| Voltage | 0.6-1 kV |
