Solar Edge Solar Inverter 3 Phase 30000W 43.5A Includes SPD plug-in

Description

Solar Inverter, 3 Phase, 45000 Watt DC Input, 680-830 Volt DC DC Operating, 43.5 Amp DC Max. Input, 30000 Watt AC Output, 30000 VA AC Max. Apparent, 50 Hz AC Operating, 43.5 Amp AC Output, +/-0.8-1 Power Factor, <3% Harmonic Distortion, 98.3% Efficiency, 98% European Weighted Efficiency, Non-Isolated PhotoVoltaic, 2000 mtr Max. Altitude, 2 x RS485, Ethernet, Wi-Fi Communication Port, Fan Cooling, <62 dBA, Bracket Mounting, IP65, -40 to 60 deg C, 808 mm Height, 317 mm Width, 300 mm Depth, 35 kg, IEC 62109, AS/NZS 3100

Key Specifications

SKU	SLRSE30K-AU00IBNV4
Brand	SolarEdge
Product Type	Inverters

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Fixed Voltage Inverter for superior efficiency 98.3% and longer strings Built-in module level monitoring with Ethernet or wireless communication for full system visibility Quick & Easy inverter Commissioning directly from a smartphone using the SolarEdge App IP65 outdoor and indoor installation Smart Energy Management Control Integrated DC Safety Unit - eliminates the need for external DC Isolators Future Ready for the SolarEdge energy storage solution
Standard Pack Size	1
UNSPSC Class	26111600
UOM	EA
Vendor Product	SE30K-AU00IBNV4
AC Max. Apparent Power	30000 VA
AC Operating Frequency	50 Hz
AC Output Current	43.5 Amp
AC Output Power	30 kW
Communication Port	2 x RS485/Ethernet/Wi-Fi
Cooling Method	Fan
DC Input Power	45000 Watt
DC Max. Input Current	43.5 Amp
DC Operating Voltage	680-830 Volt DC
Depth	300 mm
Efficiency	98.30%
European Weighted Efficiency	98%
IP Rating	IP65
Height	808 mm
Max. Operating Altitude	2000 Mtr
Mounting Method	Bracket
Noise Level	<62 dBA
Operating Temperature	-40 to 60 deg C
Phase	3 Phase
Power Factor	+/-0.8-1
Topology	Non-Isolated PhotoVoltaic
Total Harmonic Distortion	<3%
Width	317 mm
