SMA Sunny Boy Solar Inverter 2 MPPT Single Phase 3.6kW TS4 & RS485 Communication

chevron-left

Description

chevron-down
Solar Inverter, 1 Phase, 5500 Watt Input, 600 Volt DC Input, 365 Volt DC Nominal, 130-500 Volt DC MPPT Voltage Range, 125 Volt DC Start-up, 15 Amp Max. Input, 2 MPPTs, 3.6 kW Output, 3680 VA Max. Apparent, 180-280 Volt AC Operating, 220-240 Volt AC Nominal, 50 Hz, 16 Amp Output, 1, Adjustable-0.8 Overexcited to 0.8 Underexcited Power Factor, 97% Efficiency, Transformerless, WLAN/Ethernet/RS485, Smartphone, Tablet, Laptop Display, Convection Cooling, 25 dBA, SUNCLIX/AC Connector, IP65, 4K4H Climate Category, -25 to 60 deg C, 100% Relative Humidity, 435 mm Width x 470 mm Height x 176 mm Depth, 17.5 kg

Key Specifications

chevron-down
SKU
SSTSB3.6-1AV-41
Brand
SMA
Product Type
Inverters

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • One-person installation due to low weight of 17.5 kg
  • Compact design means minimum space requirements
  • 100% plug and play installation
  • Free online monitoring via sunny places
  • Automated service thanks to SMA smart connected
  • Use of surplus energy through dynamic active power limitation
  • Yield increase without installation effort due to integrated shade management SMA ShadeFix
  • Intelligent energy management and storage solutions can be added anytime
  • Can be combined with TS4-R components for module optimization
Standard Pack Size 1
UNSPSC Class 26111600
UOM EA
Vendor Product SB3.6-1AV-41
AC Max. Apparent Power 3680 VA
AC Nominal Voltage 220-240 Volt
AC Operating Frequency 50 Hz
AC Operating Voltage 180-280 Volt
AC Output Current 16 Amp
AC Output Power 3.6 kW
Communication Port WLAN/Ethernet/RS485
Climate Category 4K4H
Connection Type SUNCLIX/AC Connector
Cooling Method Convection
DC Input Power 5500 Wp
DC Input Voltage 600 Volt
DC Max. Input Current 15 Amp
DC MPPT Voltage Range 130-500 Volt
DC Nominal Voltage 365 Volt
DC Start-up Voltage 125 Volt
Depth 176 mm
Display Type Smartphone/Tablet/Laptop
Efficiency 97%
European Weighted Efficiency 96.50%
IP Rating IP65
Height 470 mm
Noise Level 25 dBA
Number of MPPTs 2
Operating Temperature -25 to 60 deg C
Phase 1 Phase
Power Factor 1/Adjustable -0.8 Overexcited to 0.8 Underexcited
Relative Humidity 100%
Topology Transformerless
Width 435 mm
