Schneider Contactor Control Relay Switching 5 Pole 10A 240V 3NO/2NC DIN Rail/Plate Mount

chevron-left

Description

chevron-down
Contactor Control Relay Switching, AC15 Rating: 240 Volt AC at 10 Amp, 240 Volt AC, 3NO/2NC, 5 Pole, Operating Time: 12-22, 4-12 ms NO, 4-19, 6-17 ms NC, Screw Clamp, DIN Rail/Base/Plate Mount, IP2x, -40 to 60 deg C, 77 mm Height, 45 mm Width, 84 mm Depth

Key Specifications

chevron-down
Barcode (EAN-13)
3389110402384
SKU
TEECAD32U7
Brand
Schneider
Range Name
TeSys Model D
Product Type
Contactors Switching

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Standard Pack Size 1
UNSPSC Class 39121500
UOM EA
Vendor Product CAD32U7
AC15 Rating 10 Amp 240 Volt
Contact Configuration 3 Normally Opened & 2 Normally Closed
Height 77 mm
Depth 84 mm
IP Rating IP2x
Mounting Method DIN Rail/Base/Plate
Number Of Poles 5 Pole
Operating Coil Voltage 240 Volt AC
Operating Time 12-22 4-12 ms NO/4-19 6-17 ms NC
Temperature -40 to 60 deg C
Terminal Connection Screw Clamp
Width 45 mm
