Schneider Circuit Breaker Motor Rated 3Pole 32A 15kW 690VAC DIN Rail Clipped Mount

chevron-left

Description

chevron-down
Miniature Circuit Breaker Motor Rated, 690 Volt AC, 32 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 416 Magnetic Rating, 15 kW Load Rating, 3 Poles, Push-Button Operator, Screw Clamp Terminal, 100000 Cycles, IP20 Conforming to IEC 60529, 35mm Symmetrical DIN Rail Clipped,-20 to 60 deg C, 89mm Height x 45mm Width x 78.5mm Depth

Key Specifications

chevron-down
Barcode (EAN-13)
3389110343298
SKU
TEEGV2ME32
Brand
Schneider
Range Name
GV2ME
Product Type
Mini Circuit Breakers

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Standard Pack Size 1
UNSPSC Class 39121600
UOM EA
Vendor Product GV2ME32
Current 32 Amp
Height 89mm
Frequency 50/60 Hz
Depth 78.5mm
Interrupt Capacity 10 kA
Load Rating 15 kW
IP Rating IP20
Magnetic Rating 416
Mounting Method DIN Rail
Operating Cycles 100000 Cycles
Number Of Poles 3 Pole
Operator Type Operators
Terminal Type Screw Clamp
Voltage 690 Volt
Temperature -20 to 60 deg C
Width 45mm
