Schneider Pilot Lamp Block Integrated LED With Screw Terminals 1N.O 110-120V Green Panel Mount 22 mm

$Schneider\Schneider_ZB4BW_LED.jpg$

Description

Pilot Lamp Block Integrated LED With Screw Terminals, Size: 22 mm, 110-120 Volt AC/DC, 3 Amp at 240 Volt AC, 6 Amp at 120 Volt AC, 0.1 Amp at 600 Volt, 1NO, Integrated LED, Slow-Break, Screw Clamp, Panel Mount, Metal, Green, -40 to 70 deg C, 47 mm Height x 30 mm Width, For Use With: Control and Signalling Units

Key Specifications

Barcode (EAN-13)	3389110893328
SKU	TEEZB4-BW0G31
Brand	Schneider
Range Name	Harmony Style 4
Product Type	Pilot Lamp Blocks

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	ZB4BW0G31
Colour	Green
Contact Configuration	1 Normally Opened
For Use With	Control and Signalling Units
Contact Operation	Slow-Break
Height	47 mm
Housing Material	Metal
Lamp Type	Integrated LED
Mounting Method	Panel
Size	22 mm
Temperature	-40 to 70 deg C
Terminal Connection	Screw/Clamp
Voltage	110-120 Volt AC/DC
Width	30 mm
