WWC 240mm SDI Cable White 500mtr
Description
SDI Cable, 240 mm, Class 5 Annealed Copper, 0.6-1 kV, 1 Core, 20.8 mm Nominal Diameter, 27.9 mm Overall Diameter, 500 mtr Length, 176 mm During Installation/117 mm After Installation Bend Radius, 1.7 mm Insulation Thickness, 0.0801 Ohm/km Conductor Resistance, White Core, X-90 XLPE Insulation, TPE Sheath, Orange Sheath, -40 to 90 deg C, AS/NZS 5000.1 AS/NZS 3808 AS/NZS 1125 AS/NZS 1660.5.6
Key Specifications
| SKU |
WWC7824XT-OR
|
|---|---|
| Brand |
WWC
|
| Range Name |
Conflex
|
| Product Type |
SDI Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 500 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 7824XT-OR |
| Bend Radius | 176 mm During Installation/117 mm After Installation |
| Conductor Resistance | 0.0801 Ohm/km |
| Conductor Size | 240 mm |
| Conductor Type | Class 5 Annealed Copper |
| Core Colours | White |
| Insulation Material | X-90 XLPE |
| Insulation Thickness | 1.7 mm |
| Nominal Diameter | 20.8 mm |
| Number of Cores | 1 Core |
| Overall Diameter | 27.9 mm |
| Sheath Colour | Orange |
| Sheath Material | TPE |
| Standards | AS/NZS 5000.1 AS/NZS 3808 AS/NZS 1125 AS/NZS 1660.5.6 |
| Temperature | -40 to 90 deg C |
| Voltage | 0.6-1 kV |
